OBESINE-Intelligent, Automation, Foods bakery Machinery Equipments OBAKING MACHINERY Smart Breads production Line
7 Years
| Ask Lasest Price | |
| Brand Name : | OBESINE |
| Model Number : | OBX-1000 |
| Certification : | CE/ISO |
| Price : | USD 30000 |
| Payment Terms : | L/C, T/T, Western Union, MoneyGram |
| Supply Ability : | 30-50 SETS Per years |
| Delivery Time : | 25 Days |
OBAKING/OBESINE Full automatic Nutrient bars production Line
It has continuous feeding pre-pressing and multi-roll rolling automatic forming, product surface is flat, density is moderate, thickness is uniform, to achieve automation; the machine uses frequency conversion technology, the movements of each part are controlled and coordinated by PLC, can adjust the speed and thickness of products and processes to achieve good results of product forming.
Automatic Forming Production Line
The production line is composed of heat preservation mixer,
flattening machine, cross cutting machine, vertical cutting
machine, etc. It is automatic production. The exterior of the
machine is made of 304 stainless steel. It is suitable for
automatic shaping of crude and miscellaneous grain products such as
peanut crisp, melon seed crisp, kernels crisp, croissant sugar, egg
crisp and corn crisp.
The continuous feeding line of nutrient bar production line
consists of automatic flattening, automatic cross cutting and
automatic vertical cutting; seven automatic leveling, with moderate
leveling density and uniform thickness; frequency conversion
adjustment, good cutting dimension and forming squareness;
continuous production of the whole machine and manual connection of
the middle realize the full automation of nutrient bar production
line. Intelligent operation.
Two technical parameters:
Production capacity: 600-1000kg/h
Whole power: 3.6 kw
Size: 6300*1300*1250mm
Weight: 1500kg
Composition of three equipment
The production line is composed of heat preservation mixer,
flattening machine, cross cutting machine, vertical cutting
machine, etc. It is automatic production. The exterior of the
machine is made of 304 stainless steel. It is suitable for
automatic forming of rice candy, Shaqima, nutcracker, egg pastry,
corn pastry and other coarse grain series.
Quadruple Nutrition Grain Bar Automatic Forming Cutting Machine
Usage: The machine is mainly suitable for cutting peanut sugar,
crocus sugar and other slices. The utility model has the advantages
of simple operation, convenient use, large production capacity,
good forming of cutting blocks and arbitrary adjustment of length
and length.
Five characteristics:
1. Paving, leveling, cutting and shaping
2. It is equipped with multi-reforming flat structure, which can be
pressed flat and uniform in thickness.
3. Frequency conversion speed regulation can meet your different
product needs.
4. Automatic cutting, time-saving, labor-saving, economic and
convenient
| Model | OBX-610 | Price |
| Power | 3KW | |
| Voltage | 380V/50HZ-60HZ | |
| Weight | 500KGS | |
| Size | 4500*1200*1350mm | |
It has all automatic continue technology, high production advanced technology. Coordinate with the chocolate spray machine, it can produce all kinds of chocolate compound products.
|
|
